- Dimensions: 108mm (W) x 40mm (H) x 98mm (D)
- Weight: 280g
- Power Supply: 12V DC 1A
- Power Consumption: 8W
- Maximum Video Resolution: Up to 1920×1200 at 60Hz, 24-bit
- Video Input: 1x HDMI 1.3
- Audio Input: Analog 16-bit, 44kHz, 2-channel
- KVM-Link Data Rate: 1 Gbps
- Maximum Distance: 150m
- Enclosure: Built-in surface mount
- Mounting: Built-in surface mount; rack mount kit available
- Operating Environment: 0 to 45°C (32 to 113°F), <80% non-condensing humidity
- Storage Environment: -25 to 80°C (-13 to 176°F), <80% non-condensing humidity
- Cooling: Free air convection
- MTBF: 82,820 hours
- Compliance: CE, FCC
- Network Switch Requirements: IGMP Snooping V2 or higher; Fast Leave enabled; Gateway bandwidth of 1 Gbit per port
