- Camera dimensions: 164 mm (H) x 910 mm (W) x 135.5 mm (D)
- Camera weight: 7.08 kg
- Power supply dimensions: 127 mm (H) x 51 mm (W) x 30 mm (D)
- Power supply weight: N/A
- DC cable length: 1.5 m
- AC cable length: 1 m
- HDMI 1.4 cable length: 2 m
- USB A to USB C 3.0 cable length: 2.2 m
- Operating system requirements: Windows 7, 8.1, 10; macOS 10.10 or higher
- Built-in components: 6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform
- Enclosure: All-in-one with integrated table stand and patented speaker suspension system
- Device management: Logitech Sync
- Display resolution: 1080p
- Physical security: Kensington Security Slot
- Main camera resolution: 4K, 1440p, 1080p, 900p, 720p, SD at 30fps
- Main camera pan: Motorized ±25°
- Main camera tilt: Motorized ±15°
- Main camera zoom: 15X HD (5X optical, 3X digital)
- Main camera diagonal field of view: 90°
- Main camera horizontal field of view: 82.1°
- Main camera vertical field of view: 52.2°
- Main camera total room coverage: 132.1° Horizontal x 82.2° Vertical
- Viewfinder camera diagonal field of view: 174°
- Viewfinder camera horizontal field of view: 150°
- Speaker drivers: 2x 70mm
- Speaker output: 90dB SPL @1W, 99dB SPL @8.0W, both ±2dB at ½ meter
- Speaker sensitivity: 90±3dB SPL at 1W, ½ meter
- Speaker total harmonic distortion: 1kHz < 2%
- Speaker sampling rate: 48 kHz
- Microphone frequency response: 90Hz – 16kHz
- Microphone sensitivity: >-36dBFS ±1dB @ 1Pa
- Microphone data rate output: 48 kHz
- Microphone pickup range: 7m
- Microphone beamforming elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
- Microphone audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
- Microphone noise suppression: AI filter
- Interfaces: 2x HDMI 1.4 Out, 1x HDMI 1.4 In, 3x Type A USB 2.0, 1x Type C USB 3.0, 10/100/1G Ethernet, 802.11a/b/g/n/ac (MIMO) WiFi
- Remote control: Bluetooth® Low Energy
- Power supply: Auto-sensing
- Operating voltage/power: 100-240V, 19V, 4.74A
