- Has Host capabilities
- Enables 2 zones of audio switching: 1 zone of amplification at 125 watts per channel and 1 zone of pre-amp output (RCA)
- DSP presets for Savant speakers
- 2 Audio inputs (1 analog, 1 digital) for distributing local audio sources
- Built-in stream of Savant Music 2.0
- Local control options (3 IR, 2 RS232)
- Can be installed surface mount with included hardware; optional rack-mount bracket available (RMB-SIPA12F-00)
- Savant Essentials subscription license enables premium features
- Operating Temperature: 32° to 104° F (0° to 40°C)
- Humidity: 10% to 90% (non-condensing)
- IR Control Ports: 3
- Serial Ports: 2 3-Pin RS232 Ports
- Dimensions: Height – 1.70 in (4.34 cm), Width – 7.89 in (20.04 cm), Depth – 7.68 in (19.50 cm)
- Net Weight: 3.5 lbs (1.59 kg)
- Shipping Weight: 5.6 lbs (2.54 kg)
- Rack Space: 1U; 2 units can be placed side-by-side in a standard 19” NEMA rack
- Power Input: 100/240V AC (50/60 Hz) 3.6A
- Maximum Power: 414W
- Rated Power (Speaker Output): 125 WPC at 4/8 ohms (THD+N < 0.1%)
- Frequency Response: 20 Hz to 20 kHz (± 0.5 dB), speaker output
- Signal-to-Noise Ratio (SNR): >100 dB, speaker output
- Ships with Savant OS – da Vinci 10
